a series of lines and arcs between points on a map

can be defined relative to a center point in two ways:

• by cartesian coordiates: x,y
• by polar coordinates: theta, radius

line can be represented in two ways:

+ by two points
+ by starting point, heading, and length

an arc can be represented as:

• two thetas, radius, direction (clockwise or counter-clockwise)

Example navigation problem: given a line AB, find the heading and length of the line

Solution:

Add point C to make a right triangle ABC, such that

• point C is the right angle c
• line AB is the hypotenuse
• angle a at point A is parallel to the x-axis, with length dx from point C
• angle b at point B is parallel to the y-axis, with length dy from point C

From the two points A,B, we know:

• angle c = 90 degrees
• dx = xB - xA, horizontal vector, length of the adjacent side
• dy = yB - yA, vertical vector, length of the opposite side
• slope of AB = dy/dx, the ratio of vertical over horizontal

Now using the equations below we can calculate the remaining factors:

• length of AB = square root of (dx squared + dy squared) # pythagorean theorem
• angle a = arcsin(dy / AB) # inverse trigonometry functions
• angle b = arccos(dx / AB)

The primary functions return the ratio of the sides, per “soh cah toa”.

• sin(a) = opp/hyp
• cos(a) = adj/hyp
• tan(a) = opp/adj

The inverse functions return the angle, given the ratio of the two sides.

• a = arcsin(opp/hyp)
• a = arccos(adj/hyp)
• a = arctan(opp/adj)

      sq(dx) + sq(dy) = sq(hyp)

The ratios of each side over the sine of its opposing angle are equal.

              opp(a)/sin(a) = opp(b)/sin(b)  = opp(c)/sin(c)

see: https://www.mathsisfun.com/algebra/trig-sine-law.html

      Heading - direction the vehicle is pointing
      Course - direction the vehicle is moving, may be different from heading due to drift
      Bearing - direction to destination or navigational aid
      Relative bearing - angle between heading and bearing

      angle - the angle within the right triangle, always < 90 degrees (in radians)
      theta - the obtuse angle indicating direction within the circle (in radians)

radians - 2pi to a circle, oriented at 3 o'clock
compass degrees - 360 to a circle, oriented to 12 o'clock

heading, course and bearing are given in compass degrees
relative bearing is given in degrees
angle and theta are given in radians

an inverse function undoes the function
arctangent is the inverse of tangent

ratio = tan(angle)      # tangent takes an angle and returns a ratio
angle = arctan(ratio)   # arctangent takes the ratio and returns the angle
slope = tan(theta)      # toa, ratio of opposite to adjacent, y/x, slope
theta = arctan(slope)   # inverse of tangent, get the angle theta from the slope

slope does not distinguish between lines going up or down
positive slope indicates a direct relationship between x and y
negative slope indicates an inverse relationship between x and y
negative change in y means line is going down, else up
negative change in x means line is going left, else right

theta does distinguish between lines going up or down
theta is an obtuse angle between 0 and 2pi
theta between 0 and pi indicates the line is going up
theta between pi and 2pi indicates the line is going down

. -dy, -dx => +slope, down to the left , quadrant 3 ll
. +dy, +dx => +slope, up   to the right, quadrant 1 ur
. -dy, +dx => -slope, down to the right, quadrant 4 lr
. +dy, -dx => -slope, up   to the left , quadrant 2 ul

theta should always be positive
arctan(negative slope) returns a negative theta

as slope approaches vertical from the right it approaches infinity
as slope approaches vertical from the left it approaches -infinity

an angle can be expressed as radians or degrees
let angle refer to the angle within a right triangle, always < 90 degrees or pi/2
let theta refer to the obtuse angle relative to the right-side x axis

slope = ratio dy/dx = tan(angle)   # tan() returns a ratio
angle = arctan(dy/dx)              # arctan() returns an angle in radians

. -90 degrees < angle < +90 degrees
.  -1.57 rads < angle < +1.57 rads      # pi/2 = 1.57

if dy/dx is negative, arctan(dy/dx) is negative (in quadrants 2 and 4)

Summary
      slope -> angle -> theta -> heading

sides -> ratio -> angle -> theta -> heading
dx,dy -> dy/dx -> arctan() -> theta -> heading
sides = dx,dy
ratio = dy/dx
angle = arctan(ratio)
theta = thetaFromAngle(angle,dx,dy)
heading = headingFromTheta(theta)

given a line AB
where
  slope is the ratio of dx,dy,  between -inf and +inf
  angle is the angle of our line to the x-axis, between -pi/2 and +pi/2 in radians
  theta is between +=2pi radians, oriented to horizontal axis pointing right
  heading is between 0-360 degrees, oriented to straight up north
  quadrant is 1,2,3, or 4

 .---slope--->    angle-> -----theta---->  heading   quadrant
                           rads   *pi degr
.+inf +dy / 0dx     1.57   1.57  0.50   90        0   vertical north
    1 +dy / +dx     0.79   0.79  0.25   45       45   ur quadrant 1
    0 0dy / +dx        0   0     0       0       90   horizontal east
   -1 +dy / -dx    -0.79   5.50  1.75  315      135   lr quadrant 4
.-inf -dy / 0dx    -1.57   4.71  1.50  270      180   vertical south
    1 -dy / -dx     0.79   3.93  1.25  225      225   ll quadrant 3
    0 0dy / -dx        0   3.14  1.00  180      270   horizontal west
   -1 +dy / -dx    -0.79   2.35  0.75  135      315   ul quadrant 2

      cartesian coordinate point: x,y
      polar coordinate point: center, theta, radius

polar coordinates

      as if, looking at a globe at the north pole

      picture a globe
      rotatated so that you are looking down on the north pole
      the prime meridian is on the right, and the international dateline is on the left
      that means the meridians are going counter-clockwise from 0 to 180
      if you go counterclockwise, the meridians are -1 to -180

      therefore,
      theta is always positive
      angle can be negative or positive
      theta originates at the positive x-axis
      angle originates at the x-axis, either negative or positive
      angle is relative to the quadrant
      theta is relative to the whole circle

      to calculate
      drawing counter-clockwise, the angle will be negative
      draw from 40 degrees to -o
      a point can be positioned

      a line between two points can only be drawn one way
      an arc between two points can be drawn two ways: cw and ccw

      wise = cw
      wise = ccw
      cw = -1
      ccw = 1

      A, B, center, radius, wise
      A, B, thetaA, thetaB, center, radius, wise

      can you calculate a center from two points?
              yes if you know the radius
      can you calculate the radius?
              yes if you know the center
      it would be the point where the lengths are equal
      and there would be two possible points


if dx is 0, we don't know if the line is going up or down options

      look at the last known heading
      don't allow identical x values in the cones array
              also scan left and right values for match

      both are given in radians
      theta indicates direction, angle does not
      in fact, angle can indicate one of four thetas, depending on quadrant
      the signs of dx,dy are required to determine quadrant

https://socratic.org/questions/how-do-you-convert-3-4-into-polar-coordinates

      heading and theta both indicate direction within a circle

      heading is given in compass degrees, 0 to 360, clockwise
      theta is given in radians, 0 to 2pi, counter-clockwise

      theta is used in the matplotlib Arc() function
      heading is used by humans

      conversion functions:
              theta = thetaFromHeading(heading)
              heading = headingFromTheta(theta)

line AB has slope, length, heading

thetafrom, theta2 difference between the two thetas, as a percentage of total theta for the circle 2pi

total length of the circle = circumference = 2pir

pct_thetadiff * circumference

versine = 1 - cosine
haversine = half versine

arc, chord, tangent

Numeric systems use signed digital numbers for latitude and longitude.

45°30'56“N becomes 45.5155556, but is it negative or positive.

In mathematical graphs,

• the centerpoint is 0,0
• points above the x-axis have a positive y-value
• points below the x-axis have a negative y-value
• y-values increase as the point moves up
• In this system,
  • the equator is at latitude 0
  • North latitudes are positive
  • South latitudes are negative

In computer graphic systems,

• 0,0 is at the top-left
• all y-values are positive and they go down
• y-values increase in value as the point moves down the screen
• In this system,
  • the equator is at latitude 0
  • North latitudes are negative
  • South latitudes are positive

In our data and programs, all coordinates use the math graph system: North is positive.

EXCEPT for the projection system. It uses the computer graphic system: North is negative.

Therefore when going to and from the projection system, we flip the sign of the latitude value.

If the line passes through two points P1 = (x1, y1) and P2 = (x2, y2) then the distance of (x0, y0) from the line is:[4]

{\displaystyle \operatorname {distance} (P_{1},P_{2},(x_{0},y_{0}))={\frac {|(x_{2}-x_{1})(y_{1}-y_{0})-(x_{1}-x_{0})(y_{2}-y_{1})|}{\sqrt {(x_{2}-x_{1})^{2}+(y_{2}-y_{1})^{2}}}}.}{\displaystyle \operatorname {distance} (P_{1},P_{2},(x_{0},y_{0}))={\frac {|(x_{2}-x_{1})(y_{1}-y_{0})-(x_{1}-x_{0})(y_{2}-y_{1})|}{\sqrt {(x_{2}-x_{1})^{2}+(y_{2}-y_{1})^{2}}}}.}
